• added a GitHub Action to create a blog post whenever I merge to main

I spent a moment updating my GitHub repos' README.md files with the help of Claude. Also added some screenshots and photos here and there:

• platform16-pcb
• platform16-firmware
• platform16-editor
• wristle (I just realised I didn't keep the PCB files. Probably on my old iMac in the attic.)
• disqo

I had this realisation that I could use euclidean rhythms on basically anything, not just on "beats". ie. if you have a string of boolean values you loop through they don't have to mean "hit or don't hit the drum", it could mean high/low, loud/quiet, open/close, accent/base, anything. All obvious to all of you, I'm sure.

When dreaming up new ideas for synth firmwares for platform 16 I found that envelopes beyond basic decay-only ones can take up a lot of the 16 knobs I have available so I wanted to try my hand at a drone synth. And then come up with basic yet interesting "one-knob" ways to add variation. So for each of the pitch, filter cutoff and volume "sections" I dedicate one knob to picking a euclidean rhythm, one to a base value and then one to an "accent" value. Worked fine as a "two-tone" thing but was a bit boring so for pitch the "accent" knob is now "choose a arpeggio mode". And then the true/false values from the rhythm becomes "advance the arpeggio or stay where you are".

I was low on knobs so the key is hardcoded (always C natural minor, can easily change it) and then the "pitch degree" knob just moves forward in that scale where it maps the chord to the "correct" major, minor, diminished or augmented cord for that note in the scale. And then three note arpeggios felt a bit limiting so I kinda arbitrarily added 7th notes to the mix. Was worried it would be limiting but I think it turned out pretty well and at a nice compromise for using so few knobs. By hardcoding the key it makes this easier to sync up with my other synths and end up with something vaguely musical anyway.

Started out as a drone and yet here it is playing something that's more "melody" than "done", but what can you do. ¯_(ツ)_/¯

Kinda proud of how "knob-efficient" it came out while remaining one-knob-per-function and not having to resort to a modal interface.

Code's here:

• firmware
• interface editor
• PCB

I tried out Claude Code on a little project - a static blog generator for this blog to be run on GitHub Pages. I used Gemini to help come up with a temporary name just so I could create the folder and move on. I asked for two words that rhyme, starting with "static" and it came up with Static Attic.

I got the html5 template from there too and got to work. I wanted a super minimal template, so I just started hand-crafting some html that would serve as the first post, the design and also an example for Claude as to what I want.

Claude helped to kickstart a CLAUDE.md. This then caused me to have all sorts of questions like what I should use for parsing YAML front matter out of a file that's otherwise markdown, what to use for rendering markdown in a GitHub Markdown compatible way, how to syntax hilight code blocks so that it generates static html with no react or other client-side JavaScript necessary.. This way I could refine the plan, the features, the tech stack, the style, etc.

One of claude's suggestions was to go with no template engine. So I figured I could just use JavaScript template strings. But then how do you render those if your template is in its own file? According to Gemini 'This is a classic "gotcha" in JavaScript.' and it taught me about the function constructor technique. Which I then told Claude to use.

I got a bit side-tracked with which node.js library to use to parse YAML front matter out of .md files since none of them seemed to have any recent updates. I settled on gray-matter after a brief detour trying front-matter in a modern TypeScript and JavaScript module setup.

Along the way I remembered that I wanted to play with TypeScript's erasable syntax so that I can execute .ts files with node directly. This meant a minimum node.js version of 24.

I also felt that it is time I try out pnpm over npm. Not that it would matter with such a simple project's lock file.

For markdown and syntax hilighting I landed on markdown-it and @shikijs/markdown-it. I realised that YouTube embeds' iframes got escaped so you would see the html rather than get the embed and Gemini pointed out that I have to pass html: true to markdown-it's options.

And that was basically it. Claude generated a working project structure with eslint, prettier, tests and everything set up on first try, it generated the validation script, it even made a build script. At some point I ran out of tokens and switched to copilot to do some minor refactors so that the style would be more like how I would do it, but really it was fine. I asked copilot to help me with the GitHub workflow so it would publish whenever I push to main, got it to fill out some tests and the README file and that was it. Done.

Admittedly the smallest project imaginable, but I'm still quite impressed with the result. And happy. I've got something small, minimal and self contained that I fully understand and can extend if/when I ever need more.

Was it faster than if I'd have written it myself? I'm not sure. I still did quite a bit of researching, thinking, planning and designing especially up front. I was still quite opinionated and particular about how I wanted it to work and what aesthetic I'm going for. We'll see how my behaviour evolves over time.

Added an arpeggiator to the new "two-tone euclidean polymeter" firmware for platform 16 this morning, reusing code from when I made the fm chord synth. So you can pick a "degree" in the scale and then it chooses the "right" chord shape for that point in the scale (major, minor, diminished, augmented) and you can arpeggiate the notes in that chord. Various arpeggio algorithms to pick form starting with off where it just plays the chord's root note.

But then in keeping with the vibe of the rest of the firmware, there's a "rhythm" at play where if the note in the rhythm is "high" it advances the arpeggio, otherwise it plays the last note. So depending on the dedensity of the "hits" in the rhythm you either have it always advance or you can play something a bit stochastic or it can just drone and rarely/slowly change the note.

And it automatically doesn't loop often or at least in an obvious way because most of these rhythms and now the arpeggio lengths are likely to be co-prime.

arpeggio.hpp is mostly vibe-coded. What's interesting is that I spent more time thinking about what I want and writing the instructions than it saved to generate the code. And that's usually the case.

Also added euclidean rhythms the other day and rhythms.hpp is the same story. Although I did generate the vectors for containing the rhythms separately using a JavaScript script.

Then the synthetic clock generator thingy was written by me manually originally then factored out manually, then it vibe-wrote the description. And got it perfectly accurate!

fun!
